Learn MoreTS 124 & TS 165
Deck Screeners
Maximize Your End Product Potential
The TS Series Deck Screeners are high-production mobile units for heavy-duty applications at work sites where site space is limited.
Contact a Sales Rep
Featured Specifications
UP TO 136 HP
42,500 - 65,000lbs
Diesel Engine
Simple to operate and maintain, the TS Series Deck Screeners are designed to work in-line or as a standalone unit on mulch, compost, aggregates, soil, sand and gravel, coal, and demolition materials.
-
Advantages
Top and Bottom Decks
Increased production capabilities by using the entire length deck on both decks.
Easy to Transport
This fully self contained plant folds up to a size that does not require a permit to transport.
Impact System in Hopper
Impact bars run the width and length of the hopper to minimize impact damages and wear and tear to the hopper.
Quick Setup and Break Down
It takes only 15 minutes to setup or break down the TS Series deck screener on the job site.
Simple to Operate
Independent variable speed controls on infeed and each conveyor.
Easy to Maintain
Quick access to the power pack for service and maintenance.
-
Exclusive Features
Telescopic Extending Side Conveyors
Telescoping fines and middle side conveyors on the TS 124 allow for greater discharge height and a full cone of material under each conveyor.
Graduated Top Deck
Ensures the entire length of the deck is utilized and allows for better flow to the bottom deck.
Three Fraction Screening
Easily screen three different sized end products in one pass. Maximizing your end product potential.
Fines Collection Conveyor
A fines collection conveyor underneath the screen allows the machine to handle the most difficult materials.
Screen Versatility
A variety of screen options and configurations are available to best suit your use case.
Quick Screen Change
Screens can be changed easily by one person.
-
Videos
TS 124 Deck Screener & 365R Radial Stacking Conveyor
The TS 124 Deck Screener is a high-production mobile unit for heavy duty applications at work sites where space is limited. The TS 124 is designed to work in-line or as a standalone unit for applications like mulch, compost, aggregates, soil, sand and gravel, coal and demolition materials. The 365R Radial Stacking Conveyor can also be used with the TS 124 Deck Screener to quickly and easily stack your product to help with efficiency and increase productivity.
Subscribe to our YouTube Channel - Industries
-
Additional Specs
Working Dimensions
TS 124
- Length: 41′
- Width: 34′ 10″
- Height: 10′ 6″
- Weight: 42,500 lbs.
TS 165
- Length: 51′
- Width: 44′
- Height: 17′
- Weight: 65,000 lbs.
Power Supply
TS 124
- 75 hp
- 95 gallon fuel tank
TS 165
- 136 hp
- 171 gall fuel tank
Additional Specifications
TS 124
- 6 cubic yard hopper
- 40″ heavy duty feeder belt
- 40″ heavy chevron overs belt
- 29″ middle & fines telescopic extending conveyors
- Output potential up to 300tph
TS 165
- 12 cubic yard hopper
- 55″ heavy duty feeder belt
- 55″ heavy chevron overs belt
- 36″ middle & fines hydraulic folding conveyors
- Output potential up to 650tph
"The first thing we look at for any screener is the consistency and quality of the finished product that is being produced. The consistency from start to finish when we are running the TS 124 Deck Screener is exactly what we were looking for."
— James Jutrzonka, Blue Ribbon Organics
